* None contact infrared temperature measurement up to 1,000 ℃ measurement.
* Type K thermocouple thermometer, up to 1400 ℃ measurement.
* Dual laser for better targeting.
* Large LCD display with back light.
* D/S ratio value : 50/1.
* Min., Max., Differential, Average, Lock mode.
* Last measurement memory.
* Hi/Lo Temperature Audio Alarm.
* Laser target and Back light On/Off control.
* Adjustable emissivity value from 0.1 to 1.00.
* Preset emissivity value at 0.95.
* Power supply by two AAA batteries, long life.
GENERAL SPECIFICATIONS
Display LCD, 31 mm x 43 mm. Measurement 8 to 14 micro meter.
Functions *℃, ℉. Wave length
*Min., Max., Differential, Average. Region
* Lock mode. Distance Factor D/S : Approx. 50:1 ( typical 25:1 ).
* Auto power off. D - Distance, S - Spot.
* LCD back light.
* Emissivity adjustment. * Distance to spot using 90%
IR -60 to 1000 ℃ ( -76 to 1832 ℉ ). encircled energy at focal point.
Measurement
Range Target Guide * Two laser target guide.
IR ± 1 ℃ ( 1.8 ℉) * Less than 1 mW.
Accuracy * Object Temp. = 15 to 35 ℃ * Class 2 red laser diode. Wave length
* Ambient Temp. = 25 ℃ is 645 nm approximately.
± 2 % of reading or ± 2 ℃ ( ± 4 ℉ ). Sampling Time Approx. 0.7 second.
whichever is greater. Power Supply DC 1.5V AAA ( UM-4 ) battery x 2 PCs,
* Object Temp. = -33 to 1000 ℃ heavy duty or Alkaline.
* Ambient Temp. = 23 ± 3℃ Power without target light on :
Type K -64 to 1400 ℃ ( -83.2 to 1999 ℉ ). Consumption Approx. DC 1.5 mA.
Thermometer with target light on :
Range Approx. DC 29.5 mA.
Type K ± 1 % of reading or ± 1 ℃ ( ± 1.8 ℉ ), Operating 0 to 50 ℃ (32 to 122 ℉).
Thermometer * Test under T ambient = 23 ± 5 ℃ Temperature
Accuracy Operating Less than 80% RH.
Resolution 0.1 ℃/0.1 ℉. < 1,000 ℃/< 1,000 ℉ Humidity
1 ℃/1 ℉. ≧1,000 ℃/≧ 1,000 ℉ Weight 386 g/0.85 LB.
Circuit Exclusive microcomputer circuit. Dimension 203 x 197 x 47 mm
Emissivity Adjustment range : 0.10 to 1.00, ( 8.0 x 7.7 x 1.8 inch )
Adjustment step 0.01. Standard Operational manual...................... 1 PC.
* 0.95 default emissivity value. Accessories Hard carrying case....................... 1 PC.
IR Thermocouple pie. DC 1.5V AAA ( UM-4 ) battery....... 2 PC.
Temp. Sensor
